Product Overview
The 880×880 double leaf SMC manhole cover features two independent cover panels, reducing the weight of each section for easier handling. Two screw locking points secure both panels to the frame. Manufactured from fiberglass reinforced composite, it is corrosion-resistant and has no recycling value.
Product Drawing
Key Features
- Double leaf design – two independent panels reduce individual cover weight for easier operation
- Two screw locking points – securely fastens each panel to the frame
- Corrosion-resistant SMC material – will not rust and has no recycling value
- Lightweight construction – simplifies handling and installation
Specifications & Dimensions
| Load Class | Clear Opening | Cover Size | Frame Size | Overall Height | Cover Thickness | Weight |
|---|---|---|---|---|---|---|
| A15 | 880x880mm | 1000x1000mm | 1135x1135mm | 70mm | 40mm | 68kg |
Technical Specifications:
- Material: SMC Composite
- Clear Opening: 880 × 880 mm
- Load Class: A15
- Standard: EN124
- Shape: Square (Double Leaf)
- Locking System: Two Screw Locks
Applications
- Telecommunications chambers
- Fiber optic networks
- Cable inspection chambers
- Electrical utility chambers
- Underground service access points
- Pedestrian areas
FAQ
What is the advantage of double leaf design?
The double leaf design features two independent cover panels, each lighter than a single large panel. This makes handling, opening, and installation easier for workers.
Can you provide OEM / ODM service?
Yes. OEM and ODM services are available. Custom logo, color, surface pattern, and dimensions can be produced according to project requirements.
What is your delivery time?
Normally, the production lead time is about 15–25 days depending on order quantity and product specifications.
What is the MOQ?
MOQ depends on the product size and specifications. Please contact us for detailed information.
What packaging method do you use?
The products are normally packed on export pallets for safer transportation and easier loading and unloading.
Do you provide warranty and after-sales service?
Yes. We provide one-year warranty service and technical support for our products. Please contact us for detailed after-sales information and project assistance.
